The Phone client

The Phone client wraps the phone section of 46elks.se docs

Available services

Dispatcher
- Make a phone call
- Multiple recipients
Receiver
- Receive a phone call
Phone actions (Incoming and outgoing)
Phone router (Incoming and outgoing)
- Basic example
- Caching routes as json "Compiling"
History

Dispatcher

The dispatcher service handles outgoing phone calls. This is how you access the phone dispatcher

use Tarre\Php46Elks\Client as Php46ElkClient;
// Initialize client
$Php46ElksClient = new Php46ElkClient('username', 'password');

$phone = $Php46ElksClient->phone()->dispatcher();

Make a phone call

To make an outgoing phonecall you need a valid number with VOICE support, you can get this number from 46elks control panel.

use Tarre\Php46Elks\Client as Php46ElkClient;
use Tarre\Php46Elks\Clients\PhoneCall\Resources\PhoneCallAction;
// Initialize client
$Php46ElksClient = new Php46ElkClient('username', 'password');

$phone = $Php46ElksClient->phone()->dispatcher();

$phone
    // set outgoing number (Must be a valid VOICE enabled e164 number from 46elks dashboard)
    ->from('+467147147417')
    // Set recipeient
    ->recipient('+4671928398')
    // When the accepts the call, play a file and hang up
    ->voiceStart(function(PhoneCallAction $action){
        return $action
            ->play('http://yourapp.com/wav/hello.wav')
            ->hangUp();
});

Multiple recipients

You can use the setRecipients method to make multiple outgoing calls in one fell swoop, all calls will be async.

use Tarre\Php46Elks\Client as Php46ElkClient;
use Tarre\Php46Elks\Clients\PhoneCall\Resources\PhoneCallAction;
// Initialize client
$Php46ElksClient = new Php46ElkClient('username', 'password');

$phone = $Php46ElksClient->phone()->dispatcher();

$phone
    // set outgoing number (Must be a valid VOICE enabled e164 number from 46elks dashboard)
    ->from('+467147147417')
    // Set recipeient(s)
    ->setRecipients([
        '+46719283981',
        '+46719283982',
        '+46719283983',
        '+46719283984',
])
    // When the accepts the call, play a file and hang up
    ->voiceStart(function(PhoneCallAction $action){
        return $action
            ->play('http://yourapp.com/wav/hello.wav')
            ->hangUp();
});

Receiving phone calls

The receiver service handles incoming phone calls. This is how you access the phone receiver

// Via base client
use Tarre\Php46Elks\Client as Php46ElkClient;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;
// Initialize client
$Php46ElksClient = new Php46ElkClient('username', 'password');

$phone = $Php46ElksClient->phone()->receiver();

// without client
$phone = new PhoneCallReceiverService;

NOTE: Receiving phone calls requires your PHP application to be exposed to 46elks.com`s webhooks.

Receive a phone call

Receiving phone calls is pretty straight forward, 46elks.com sends an POST request to the web hook to the url you provided in their control panel.

When your app receives the message, you can read certain data and peform some actions.

use Tarre\Php46Elks\Client;
use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;

$Php46ElksClient = (new Client('username', 'password'));

$receiver = $Php46ElksClient->phone()->receiver();

return $receiver->handleRequest(function(ReceivedPhoneCall $phoneCall){

    // You wont be able to see this print_r result, so replace it with some log function of yours
    print_r([
        $phoneCall->callId(),
        $phoneCall->created(),
        $phoneCall->direction(),
        $phoneCall->from(),
        $phoneCall->to()
    ]);

    // You wont be able to see this print_r result, so replace it with some log function of yours
    print_r($phoneCall->toArray());

    // handle the phone call by playing a soundfile, then hanging up
    return $phoneCall
        ->action()
        ->play('http://yourapp.com/elks/soundfile.mp3') // play this file
        ->hangUp(); // hangup the call
});

Phone actions (Incoming and outgoing)

Whether you are making outgoing calls or receiving incoming calls, the PhoneCallAction class can be accessed to peform certains actions to the active call.

All examples will be presented as received calls without the base client

Connect
Play
IVR
Record
Recordcall
Hangup

Action: connect

Connect the call to a given number, and in the case of an answer, let the two callers speak to each other.

use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;

return (new PhoneCallReceiverService)->handleRequest(function(ReceivedPhoneCall $phoneCall){

    return $phoneCall
        ->action()
        ->connect('+46701464412');
});

Action: play

Play an audio file or predefined sound. Could be either a URL on your server or a sound resource provided by 46elks.

use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;

return (new PhoneCallReceiverService)->handleRequest(function(ReceivedPhoneCall $phoneCall){

    return $phoneCall
        ->action()
        ->play('http://yourapp.com/welcome.mp3');
});

Action: IVR

The “ivr” action fills the purpose of playing a sound resource while also retrieving digits pressed by the caller (think customer support menus etc.). Once a key is pressed the url in next will recieive a post request with an query param called result with the key pressed, so if the 3 key was pressed the url would end up like this http://yourapp.com/ivr-test.php?result=3

use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;

return (new PhoneCallReceiverService)->handleRequest(function(ReceivedPhoneCall $phoneCall){

    return $phoneCall
        ->action() // access phone call actions
        ->ivr('welcome.mp3')
        ->next('http://yourapp.com/ivr-test.php'); // go back to the same url. Effectively a loop
});

You can also supply phone actions for the different alternatives directly.

use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;

return (new PhoneCallReceiverService)->handleRequest(function(ReceivedPhoneCall $phoneCall){

    return $phoneCall
        ->action() // access phone call actions
        ->ivr([
                    'ivr' => 'welcome.mp3', //play this when call is connected
                    '1' => $phoneCall->action()->play('hours.mp3'), // if the caller presses 1, play opening hours
                    '2' => $phoneCall->action()->connect('+467014674527'), // if the caller presses 2, connect them to customer service
                ])
        ->next('http://yourapp.com/ivr-test.php'); // repeat
});

Action: Record

This action records the voice of the caller.

use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;

return (new PhoneCallReceiverService)->handleRequest(function(ReceivedPhoneCall $phoneCall){

    return $phoneCall
        ->action() // access phone call actions
        ->recordCall('https://yourapp.example/elks/recordings')
        ->connect('+46780121241')// Or any other action
        ->next('https://yourapp.example/elks/calls'); // optional
});

Action: Record call

This action records the entire call and sends out a webhook with a link to the recording when the call ends. This action cannot be used by itself, it triggers at the same time as another action.

use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;

return (new PhoneCallReceiverService)->handleRequest(function(ReceivedPhoneCall $phoneCall){

    return $phoneCall
        ->action() // access phone call actions
        ->record('https://yourapp.example/elks/recordings')
        ->next('https://yourapp.example/elks/calls'); // optional
});

Action: Hangup

End the call. If this is your first action, it is possible to control signalling, otherwise only "reject" is allowed.

use Tarre\Php46Elks\Clients\PhoneCall\Resources\ReceivedPhoneCall;
use Tarre\Php46Elks\Clients\PhoneCall\Services\PhoneCallReceiverService;

return (new PhoneCallReceiverService)->handleRequest(function(ReceivedPhoneCall $phoneCall){

    return $phoneCall
        ->action() // access phone call actions
        ->play('https://yourapp.example/elks/recordings')
        ->hangUp('reject'); // optional
});

To learn more about call actions, please consult this portion of the documentation. All call actions are reflected as functions via PhoneCallAction

Phone router

The phone router handles incoming requests.

Basic example

This is the scenario:

When you dial +46xxxxx You are presented with a soundfile telling you which buttons do what: Press 1 for hours Press 2 to talk with an employee Option 1 just plays a soundfile then hangs up Option 2 connets the caller to another number

Assuming this code exists in http://yourapp.com/elks/calls and voice_start @ 46elks.com points to http://yourapp.com/elks/calls

use Tarre\Php46Elks\Client;
use Tarre\Php46Elks\Clients\PhoneCall\Resources\PhoneCallAction;

/* Set the baseURL for all actions and webhooks (Optional) */
Client::setResourceBaseUrl('http://yourapp.com/elks/calls');

$Php46ElksClient = (new Client('username', 'password'));

$router = $Php46ElksClient->phone()->router();

$router->default(function(PhoneCallAction $action){
    return $action
        ->ivr('choices.mp3')
        ->next('', ['action' => 'ivr']); // This will create a loopback to this action again
});

$router->register('ivr1', function(PhoneCallAction $action){
    return $action
        ->play('hours.mp3') // opening hours will be presented
        ->next('', ['action' => 'ivr']); // This will redirect the call to "http://yourapp.com/elks/calls.php?action=ivr"
});

$router->register('ivr2', function(PhoneCallAction $action){
    return $action
        ->connect('+467013212321');
});

// At first glance, this looks weird. But it makes sense.
$action = isset($_REQUEST['action']) ? $_REQUEST['action'] : '';
$digits = isset($_REQUEST['digits']) ? $_REQUEST['digits'] : '';
// As you saw above this example, we assumed the calls initial endpoint is `.../calls`
// And according to https://46elks.se/docs/voice-ivr the IVR action will make a request with an added query param called `digits`
// That means that when the user inputs 1 on their phone, 46elks will make this request `calls.php?action=ivr&digits=1`
// Therefore we can match those

// Handle registered routes. This action will return a JSON that 46elks reads.
$actionName = $action . $digits;

return $router->handle($actionName);

Caching routes as json "Compiling"

if you want to save different routes dynamically you can save and load routes with compile

use Tarre\Php46Elks\Client;
use Tarre\Php46Elks\Clients\PhoneCall\Resources\PhoneCallAction;

/* Set the baseURL for all actions and webhooks (Optional) */
Client::setResourceBaseUrl('http://yourapp.com/elks/calls');

$Php46ElksClient = (new Client('username', 'password'));

$router = $Php46ElksClient->phone()->router();

$router->default(function(PhoneCallAction $action){
    return $action
        ->ivr('choices.mp3')
        ->next('', ['action' => 'ivr']); // This will create a loopback to this action again
});

// save
$router->compile();

$compiledRoutes = $router->toJson();

// load json
$router->compile(json_decode($compiledRoutes, true));

History

This is how you fetch call history from 46elks.

Notes

Log retention is set in your account settings

Get all history

use Tarre\Php46Elks\Client as Php46ElkClient;
// Initialize client
$Php46ElksClient = new Php46ElkClient('username', 'password');

$history = $Php46ElksClient->phoneCall()->history();

$paginator = $history->get();

foreach($paginator->getData() as $PhoneCall){
    print_r([
        'direction' => $PhoneCall->direction(),
        'id' => $PhoneCall->id(),
        'from' => $PhoneCall->from(),
        'to' => $PhoneCall->to(),
        'created' => $PhoneCall->created(),
        'cost' => $PhoneCall->cost()
    ]);
}

Filter requests

There exists a couple of filter settings you can use to search and narrow your results

start($date) Retrieve PhoneCall before this date.
end($date) Retrieve PhoneCall after this date.
limit($number) Limit the number of results on each page.

These filters MUST to be used before get is invoked. After get has been invoked, you can use next() to get the next "page"

use Tarre\Php46Elks\Client as Php46ElkClient;
// Initialize client
$Php46ElksClient = new Php46ElkClient('username', 'password');

$history = $Php46ElksClient->phone()->history();

$paginator = $history
    ->start('2020-02-14T09:52:07.302000')
    ->end('2020-02-15T09:52:07.302000')
    ->get();

foreach($paginator->getData() as $PhoneCall){
    print_r([
        'direction' => $PhoneCall->direction(),
        'id' => $PhoneCall->id(),
        'from' => $PhoneCall->from(),
        'to' => $PhoneCall->to(),
        'created' => $PhoneCall->created(),
        'cost' => $PhoneCall->cost()
    ]);
}

Get single

To retrieve a single resource you can invoke the getById instead of get

use Tarre\Php46Elks\Client as Php46ElkClient;
// Initialize client
$Php46ElksClient = new Php46ElkClient('username', 'password');

$history = $Php46ElksClient->phone()->history();

$PhoneCall = $history->getById('enter phoneCall id here');

print_r([
    'direction' => $PhoneCall->direction(),
    'id' => $PhoneCall->id(),
    'from' => $PhoneCall->from(),
    'to' => $PhoneCall->to(),
    'created' => $PhoneCall->created(),
    'cost' => $PhoneCall->cost()
]);

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

The Phone client

Available services

Dispatcher

Make a phone call

Multiple recipients

Receiving phone calls

Receive a phone call

Phone actions (Incoming and outgoing)

Action: connect

Action: play

Action: IVR

Action: Record

Action: Record call

Action: Hangup

Phone router

Basic example

Caching routes as json "Compiling"

History

Get all history

Filter requests

Get single

FilesExpand file tree

call.md

Latest commit

History

call.md

File metadata and controls

The Phone client

Available services

Dispatcher

Make a phone call

Multiple recipients

Receiving phone calls

Receive a phone call

Phone actions (Incoming and outgoing)

Action: connect

Action: play

Action: IVR

Action: Record

Action: Record call

Action: Hangup

Phone router

Basic example

Caching routes as json "Compiling"

History

Get all history

Filter requests

Get single
