Closes #8610.
Scope correction
The issue described recharts as "a direct UI dependency (
apps/loopover-ui/package.json)". It is actually declared in three workspaces:apps/loopover-ui^2.15.4^3.10.1apps/loopover-miner-ui^2.15.4^3.10.1packages/loopover-ui-kit(published)^2.15.4^3.10.1Bumping only the one named would have left two majors resolved in the same tree — a worse problem than the warning it fixes: two copies bundled, and the published ui-kit's chart primitives drifting from the app's. The lockfile now resolves exactly one version.
Three real v3 breaks
Each fixed by reading the library's own exported types rather than restating them locally, so the next such change is a compile error instead of silent drift:
Line'sdotrender prop (sparkline.tsx) — v3 widenedkeyfromstringto React'sKey, which the hand-written parameter annotation silently disagreed with. The props are derived fromLine's own signature now.Tooltip/Legendcontent (ui-kit/chart.tsx) — v3 movedpayloadandlabeloff the components' props (they are read from context) and publishesTooltipContentProps/LegendPayloadfor the render-prop shape.item.dataKey— v3 letsdataKeybe a function accessor, which is not a valid key. The correct string was already computed two lines above and is used instead.The sparkline had no test
Which is a poor place to be for a chart-library major bump: a type-clean upgrade that renders nothing looks exactly like a passing build. It has one now, asserting a line path is actually drawn, that an all-null series renders nothing rather than a flat line at zero, and that a partial-null series still renders (the
connectNulls={false}gap is the "insufficient data" signal).ResponsiveContainermeasures its parent and jsdom reports 0×0 for everything, so the component's own fixed pixel box is stubbed in the harness — without that recharts correctly draws nothing and every assertion would pass vacuously. Verified by mutation: forcing the early return kills 3 of the 4 cases.Validation
ui:typecheckclean,ui:lint0 errors,ui:buildand the miner-UI build clean.test:ui-kit-packclean (161 files) — the published package still packs.npm audit --audit-level=moderate: 0 vulnerabilities.npm ci. The two@esbuild-kit/*warnings that remain are Trace and replace the @esbuild-kit/* transitive dependency (merged into tsx upstream) #8609's, which is blocked upstream — analysis posted there.No visual evidence table: this is a library migration with no intended visual change, and the sparkline is a 64×28px axis-less glyph. The new tests assert the render output directly instead.
