tracebook

Latency-focused order book simulation with reproducible benchmarks, lifecycle events, and trace-level profiling hooks.

TL;DR: tracebook is an alpha Python market microstructure workbench for testing order book matching semantics, synthetic order flow, cancellations, replacements, benchmark latency, and profiling instrumentation. It is built for systems engineers and quant-minded developers who want inspectable behavior before making performance claims.

Video Walkthrough

Watch Trace The Match on YouTube: https://youtu.be/RXOcB2k7qTQ

Best Way To Review

1. Run the unit tests and system smoke.
2. Execute a deterministic simulation with cancel and replace events.
3. Generate a benchmark JSON report with warmup excluded.
4. Launch the dashboard demo if you want live depth and performance telemetry.
5. Read the claims, non-claims, and limitations before treating any number as a production latency claim.

python -m pip install -e ".[dev,dashboard]"
python -m pytest
python test_system.py
tracebook-sim --duration 1 --throughput 50 --algorithm FIFO --seed 1337 --cancel-ratio 0.05 --replace-ratio 0.02 --warmup-seconds 0.01
tracebook-benchmark --scenario smoke --seed 1337 --warmup-seconds 0.01 --output benchmark_results/smoke.json

Why This Matters

Order book projects are easy to overstate. A simulator can advertise high throughput while silently mixing order generation time into matching latency, ignoring cancellations, using only integer quantities, or skipping basic exchange-style order semantics.

tracebook takes the opposite path. It keeps the matching behavior explicit, separates generation and matching metrics, supports lifecycle events, validates incoming orders, and publishes benchmark output as reproducible local artifacts rather than universal performance claims.

The goal is a credible open-source alpha: small enough to audit, complete enough to demonstrate real mechanics, and honest enough that future optimization work has a stable baseline.

Current Local Benchmark Snapshot

The sample below is a local smoke baseline, not a portable performance claim. It was measured on May 9, 2026 with Python 3.11.5 on macOS 15.4.1 using:

tracebook-benchmark --scenario all --duration 1 --throughput 100 --seed 2026 --warmup-seconds 0.05 --output /private/tmp/tracebook-benchmark-doc-baseline-current.json

Scenario	Orders	Throughput ops/s	Mean ms	P50 ms	P95 ms	P99 ms	Generation mean ms	Event mean ms	Memory MB
smoke	100	99.93	2.922	0.060	0.219	3.186	0.855	0.000	134.28
fifo_baseline	110	109.98	0.139	0.112	0.363	0.512	1.181	0.000	134.31
pro_rata_baseline	100	99.93	0.124	0.095	0.398	0.630	0.868	0.000	134.19
cancellation_mix	112	111.53	0.130	0.087	0.369	0.590	1.752	0.036	100.03

See docs/performance.md before adding or changing benchmark claims.

Current Artifact Proof

All checks below were run during the latest production repo pass in this checkout.

Proof surface	Verified result
Unit tests	70 pytest tests passing
System smoke	python test_system.py passes all 4 checks
Format and lint	python -m black --check src tests examples install_deps.py and python -m flake8 src tests examples install_deps.py report 0 issues
Compile and dependency checks	python -m compileall -q src tests examples install_deps.py and python -m pip check pass
Package build	sdist and wheel build successfully
Simulation CLI	deterministic FIFO smoke run completes
Benchmark CLI	smoke scenario writes JSON report
Dashboard loop	dashboard factory/import works, help completes, and local demo server returns HTTP 200 on loopback
Remote CI	GitHub Actions passes on Python 3.10 and 3.11

What It Implements

Component	What it does	Why it matters
FIFO matching	Matches resting orders by price-time priority	Provides the standard exchange-style baseline
Pro-rata matching	Allocates fills by resting size at a price level	Supports futures-style allocation experiments
Decimal quantities	Handles float quantities for crypto-style sizing	Avoids legacy integer-only simulator behavior
Order types	Supports limit, market, IOC, and FOK semantics	Covers common execution workflows
Lifecycle APIs	Cancels, replaces, active-order lookup, and structured OrderResult submissions	Makes simulations and demos inspectable
Event simulation	Interleaves NEW, CANCEL, and REPLACE events with deterministic seeds	Exercises more than one-way order ingestion
Synthetic streams	Generates random, trend, mean-reverting, momentum, passive, market-making, aggressive, and mixed flows	Enables repeatable workload variation
Performance monitor	Tracks throughput, latency, resources, generation time, event latency, and overhead	Separates signal from instrumentation cost
Benchmark runner	Runs fixed scenarios with warmup and machine metadata	Makes performance regression checks reproducible
Dashboard demo	Starts a Dash dashboard with optional background simulation	Gives a live review path without external services
CI and packaging	Tests, lint, smoke runs, benchmark smoke, dashboard smoke, and wheel/sdist build	Keeps the repo usable for contributors

Architecture

flowchart LR
    A["OrderFactory / user API"] --> B["OrderBook"]
    B --> C["Validation"]
    C --> D["MatchingEngine"]
    D --> E1["FIFO path"]
    D --> E2["Pro-rata path"]
    D --> F["Price levels"]
    F --> G["Trades + resting book"]
    G --> H["Market data snapshots"]
    I["SyntheticOrderStream"] --> J["Simulation events"]
    J --> B
    B --> K["PerformanceMonitor"]
    K --> L["Benchmark JSON"]
    K --> M["Dashboard"]
    H --> M

Loading

Core paths:

• src/tracebook/core/order.py: order, trade, side/type enums, and order factory.
• src/tracebook/core/orderbook.py: public book API, validation, lifecycle operations, callbacks, snapshots.
• src/tracebook/core/matching_engine.py: FIFO and pro-rata matching coordination.
• src/tracebook/core/price_level.py: price-level storage and depth snapshots.
• src/tracebook/simulation/: synthetic order streams and event-based simulation engine.
• src/tracebook/benchmarks/runner.py: reproducible benchmark scenarios and JSON reports.
• src/tracebook/profiling/: performance monitor and magic-trace/fallback profiling.
• src/tracebook/visualization/dashboard.py: Dash dashboard and demo simulation entry point.

See docs/architecture.md for the deeper component map.

Quick Start

Install locally:

git clone https://github.com/Taz33m/tracebook.git
cd tracebook
python -m venv venv
source venv/bin/activate
pip install -e ".[dev,dashboard]"

Run a minimal match:

from tracebook import OrderBook, OrderSide

book = OrderBook("BTCUSD", matching_algorithm="fifo")

book.add_limit_order(OrderSide.BUY, price=50_000.0, quantity=1.0)
trades = book.add_limit_order(OrderSide.SELL, price=49_999.0, quantity=0.5)

for trade in trades:
    print(trade.quantity, trade.price)

Use structured result APIs when the caller needs lifecycle detail:

from tracebook import OrderBook, OrderSide

book = OrderBook("BTCUSD")

result = book.submit_limit_order(OrderSide.BUY, price=49_950.0, quantity=0.25)

print(result.order.order_id)
print(result.rested)
print(result.cancelled)
print(result.rejected_reason)

Order Lifecycle Example

from tracebook import OrderBook, OrderSide

book = OrderBook("ETHUSD")

resting = book.submit_limit_order(OrderSide.BUY, price=3_000.0, quantity=2.0)
order_id = resting.order.order_id

print(book.get_active_order_ids())
print(book.get_order(order_id).remaining_quantity)

replacement = book.replace_order(order_id, price=3_001.0, quantity=1.5)
print(replacement.rested, replacement.rejected_reason)

cancelled = book.cancel_order(replacement.order.order_id)
print(cancelled)

Simulation

Run a deterministic FIFO simulation with cancel and replace events:

tracebook-sim \
  --duration 5 \
  --throughput 500 \
  --algorithm FIFO \
  --seed 1337 \
  --cancel-ratio 0.05 \
  --replace-ratio 0.02 \
  --warmup-seconds 0.05 \
  --output benchmark_results/simulation.json

Run the pro-rata path:

tracebook-sim --duration 5 --throughput 500 --algorithm PRO_RATA --seed 1337

Enable magic-trace integration or fallback tracing:

tracebook-sim --duration 5 --throughput 500 --algorithm FIFO --magic-trace

Reproducible Benchmarks

tracebook-benchmark \
  --scenario all \
  --seed 1337 \
  --warmup-seconds 0.05 \
  --output benchmark_results/local.json

Scenarios:

Scenario	Purpose
smoke	Short CI-friendly FIFO run
fifo_baseline	FIFO matching baseline
pro_rata_baseline	Pro-rata matching baseline
cancellation_mix	FIFO run with cancel and replace events
all	Runs every scenario above

Benchmark JSON includes machine metadata, dependency versions, scenario config, seed, warmup, throughput, matching latency percentiles, generation latency, lifecycle event latency, memory, and monitoring overhead.

See docs/performance.md for local baseline guidance and sample measured results.

Dashboard

tracebook-dashboard --port 8050 --demo-simulation --demo-throughput 200 --seed 1337

Open http://localhost:8050 to inspect live throughput, latency, resource usage, trade volume, and book depth. The dashboard binds to loopback by default; non-loopback hosts require --allow-remote because the demo dashboard has no authentication.

Dashboard dependencies are optional:

pip install -e ".[dashboard]"

Command Surface

Command	Purpose
tracebook-sim --duration 5 --throughput 500 --algorithm FIFO	Run a FIFO simulation
tracebook-sim --algorithm PRO_RATA --seed 1337	Run the pro-rata path deterministically
tracebook-sim --cancel-ratio 0.05 --replace-ratio 0.02	Interleave lifecycle events
tracebook-sim --output results.json	Export simulation results
tracebook-benchmark --scenario smoke	Run the benchmark smoke scenario
tracebook-benchmark --scenario all --output benchmark_results/local.json	Produce a full local benchmark report
tracebook-dashboard --demo-simulation	Launch the dashboard with live demo data
python -m pytest	Run unit tests
python test_system.py	Run integration smoke checks
python -m build --sdist --wheel --outdir dist	Build package artifacts

See docs/commands.md for CLI options and review workflows.

Python API

from tracebook import OrderBook, OrderBookManager, OrderSide

manager = OrderBookManager()
book = manager.create_order_book("BTCUSD", matching_algorithm="fifo")

book.submit_limit_order(OrderSide.BUY, 50_000.0, 1.0)
book.submit_limit_order(OrderSide.BUY, 49_950.0, 0.25)

result = book.submit_ioc_order(OrderSide.SELL, 49_900.0, 0.5)

print(len(result.trades))
print(book.get_best_bid())
print(book.get_best_ask())
print(book.get_order_book_depth(levels=3))
print(book.get_statistics())

Public top-level exports:

Export	Purpose
OrderBook	Single-symbol order book
OrderBookManager	Multi-symbol book registry
OrderFactory	Explicit order construction
OrderResult	Structured submission result
OrderSide	BUY and SELL enum
OrderType	MARKET, LIMIT, IOC, FOK enum
Trade	Executed trade record

Outputs

Output	Description
Simulation JSON	Raw simulation config, summary metrics, performance data, order book stats, stream stats, algorithm analysis
Benchmark JSON	Scenario summaries plus raw simulation results, machine metadata, dependency versions, warmup and seed
Dashboard charts	Throughput, latency, resources, trade volume, and depth
Performance docs	Local baseline samples and reporting rules

Generated benchmark outputs and trace artifacts are ignored by git.

Repository Layout

src/tracebook/              package source
  core/                     orders, price levels, matching engine, order book API
  algorithms/               FIFO and pro-rata analysis helpers
  simulation/               synthetic order streams and event simulation
  benchmarks/               reproducible benchmark runner
  profiling/                performance monitor and tracing tools
  visualization/            Dash dashboard
tests/                      pytest correctness and integration coverage
docs/                       architecture, commands, and performance notes
examples/                   runnable example scripts
.github/workflows/          CI across supported Python versions
setup.py                    package metadata, extras, console scripts
pyproject.toml              build-system and tool configuration

Claims And Non-Claims

Claims:

• Implements FIFO and pro-rata matching paths for supported order types.
• Supports decimal order quantities.
• Validates symbols, sides, order types, prices, and quantities before matching.
• Supports cancellation, replacement, active order lookup, and book-depth snapshots.
• Runs deterministic synthetic simulations with new, cancel, and replace events.
• Reports benchmark output with warmup, seed, machine metadata, generation timing, matching latency, event latency, memory, and monitoring overhead.
• Provides a dashboard demo path without requiring external market connectivity.

Non-claims:

• Not a production exchange matching engine.
• Not a trading venue, broker, market data vendor, or exchange connector.
• Not investment advice.
• Not a guarantee of live low-latency performance.
• Not a fixed-point/tick-index implementation yet.
• Not a complete market microstructure research platform.
• Not proof that a listed benchmark number will reproduce on another machine.

Limitations

• Alpha software; APIs may still evolve before a stable v1 release.
• Current storage uses Python dictionaries and lists around Numba-accelerated helper paths, not a final low-latency memory layout.
• Prices and quantities are float64-style values; fixed-point accounting is a later performance phase.
• Synthetic order flow is useful for workload testing, not a substitute for real exchange data.
• Dashboard is a local demo and monitoring surface, not a secured production service.
• Magic-trace is optional and platform-dependent; fallback profiling is available when magic-trace is not installed.
• Benchmark results are local artifacts and should always cite the command, seed, machine, Python version, and dependency versions.

Roadmap

Near-term production hardening:

• Add a meaningful mypy baseline after cleaning current typing noise.
• Expand benchmark scenarios for deeper book sweeps, multi-symbol runs, and higher cancellation mixes.
• Add more artifact-level tests around exported JSON schemas.
• Introduce fixed-point price and quantity experiments behind benchmark evidence.
• Publish release artifacts once the alpha API stabilizes.

Open Source Project Health

• Contribution guide: CONTRIBUTING.md
• Security policy: SECURITY.md
• Code of conduct: CODE_OF_CONDUCT.md
• Support guide: SUPPORT.md
• Changelog: CHANGELOG.md
• Project plan: PROJECT_PLAN.md

Pull requests should include tests and should not add benchmark claims without a reproducible command and machine context.

License

MIT License. See LICENSE.
