… proxy client Remote bindings were wired locally as a proxy worker that only relayed fetch/JSRPC, so `binding.connect(address)` against a raw-TCP binding (e.g. a VPC network) failed with "Incoming CONNECT on a worker not supported". Add an inbound `connect` handler to the proxy client worker: it recovers the target address from `socket.opened.localAddress` (the verbatim `connect()` authority, per workerd#6059), opens a dedicated WebSocket to the remote proxy server, and relays bytes in both directions via a new `pipeSocketOverWebSocket` helper (with `truncateCloseReason` for the 123-byte close-reason limit). The relay tears both directions down together so a parked read or a missing close event can't leak the socket. The inbound connect handler is experimental-gated in workerd, so opt the proxy client worker into the `experimental` compat flag only for raw-TCP bindings via a new `rawTcp` option on `remoteProxyClientWorker`; VPC networks pass it. The existing HTTP/JSRPC proxy call sites are unchanged. Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
…orker The remote-bindings proxy server now detects the WebSocket connect upgrade (carrying the target in `MF-Connect-Address`), opens the real binding socket via `fetcher.connect(address)`, and relays bytes bidirectionally over the WebSocket. This is the edge half of the Miniflare `connect()` tunnel. The relay helper is a byte-for-byte mirror of the one in miniflare's remote-bindings-utils; this template is bundled standalone for the edge, so the logic is duplicated here rather than imported. Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
Add 13 tests for the `connect()` tunnel: end-to-end byte relay and address propagation plus a close/error matrix run against the real bundled ProxyServerWorker (in a second "edge" Miniflare instance), unit coverage of `pipeSocketOverWebSocket` teardown/error paths, and opt-in assertions that the `experimental` flag is set only when `rawTcp` is requested. Add a `@relay-under-test` vitest alias so the worker-side relay helper can be unit-tested without pulling worker-typed source into the node-side tsconfig (which excludes `src/workers/**`). Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
mack-erel
force-pushed
the
vpc-network-connect-tunnel
branch
from
July 21, 2026 03:05
d3b9589 to
bc96fcb
Compare
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
2 participants
Add this suggestion to a batch that can be applied as a single commit.This suggestion is invalid because no changes were made to the code.Suggestions cannot be applied while the pull request is closed.Suggestions cannot be applied while viewing a subset of changes.Only one suggestion per line can be applied in a batch.Add this suggestion to a batch that can be applied as a single commit.Applying suggestions on deleted lines is not supported.You must change the existing code in this line in order to create a valid suggestion.Outdated suggestions cannot be applied.This suggestion has been applied or marked resolved.Suggestions cannot be applied from pending reviews.Suggestions cannot be applied on multi-line comments.Suggestions cannot be applied while the pull request is queued to merge.Suggestion cannot be applied right now. Please check back later.
Fixes #14710.
What
Adds raw-TCP
connect()support for remote VPC Network bindings in local development. Previously,env.VPC_NETWORK.connect("host:port")worked when deployed but failed underwrangler dev/getPlatformProxy()withIncoming CONNECT on a worker not supported, because the local remote-bindings proxy only relayed HTTP and JSRPC.Raw TCP is now tunnelled end-to-end through the existing remote-bindings proxy:
packages/miniflare/src/workers/shared/remote-proxy-client.worker.ts) gains an inboundconnect(socket)handler. It recovers the caller's target address, opens a WebSocket to the remote proxy server, and relays bytes in both directions.ProxyServerWorker(packages/wrangler/templates/remoteBindings/ProxyServerWorker.ts) gains a WebSocket tunnel endpoint that callsenv[binding].connect(address)(routing through the real VPC tunnel) and relays bytes back.connecthandler only for raw-TCP bindings (VPC networks today).Why
The full root-cause analysis, source trace, and feasibility spikes are in #14710, so only a summary is repeated here. In short: remote-capable bindings are wired locally as a proxy worker that implements
fetch()/capnweb JSRPC only.env.BINDING.connect(addr)is a native workerd path that delivers an inbound CONNECT to that worker's entrypoint, which workerd rejects unless the worker carries theconnect_pass_throughorexperimentalcompat flag. Neither the proxy client nor the edge proxy server had a socket relay path, so the call died locally before ever reaching the remote proxy session.Design decisions
connecthandler (workerd#6059): the proxy client worker implementsexport default { connect(socket) }. This handler is experimental-gated in workerd, so it is enabled via a per-workerexperimentalcompat flag rather than relying on Miniflare's global--experimentalCLI flag (which is not sufficient — the check is per-worker).socket.opened.localAddress: the authority passed toconnect("host:port")arrives verbatim as the inbound socket'slocalAddresson the service-binding path, matching workerd'sconnect-handler-test.jscontract. No extra address-negotiation protocol is needed; the address is forwarded to the edge in anMF-Connect-Addressheader.connect(): each tunnel opens its own WebSocket to the proxy server rather than multiplexing over the existing capnweb JSRPC session. This keeps the relay independent of the JSRPC framing and simple to reason about for teardown.rawTcpopt-in (existing call sites unaffected):remoteProxyClientWorker()takes a newoptions?: { rawTcp?: boolean }parameter; only VPC networks pass{ rawTcp: true }. All existing HTTP/JSRPC proxy call sites keep their current behaviour and do not enable theexperimentalflag.Open questions (happy to adjust to maintainer preference)
Both of these are unchanged from the questions raised in #14710 and can be reshaped however maintainers prefer:
experimentalcompat flag on Miniflare's internal proxy-client worker (scoped to raw-TCP bindings), because workerd#6059's inbound connect handler is not yet stable. If maintainers would rather not enableexperimentalon the internal worker, this could instead be gated behind an--experimental-*Wrangler flag per the naming conventions inCONTRIBUTING.md.connect()for simplicity. It could instead reuse the existing capnweb WebSocket session if a single multiplexed connection is preferred.Known limitations
Documented in the relay's code comments as well:
socket.readableis drained as fast as it produces; inbound WebSocket messages are written to the socket in order via a serialised write chain.Testing
New test file
packages/miniflare/test/plugins/shared/remote-bindings-connect.spec.ts— 13 tests total:ProxyServerWorker(run in a second "edge" Miniflare instance) and asserts theconnect()address is forwarded verbatim.pipeSocketOverWebSocketunit (7): clean WS close cancels the parked socket read and resolves; socket EOF closes the WS and settles the WS-wait direction; a remote1011close rejects and cancels the opposite direction; a WSerrorevent rejects, cancels, and closes the writer; a socket read error closes with1011and rejects; a socket write failure tears down with1011and rejects; the1011close reason is truncated to <=123 UTF-8 bytes on a char boundary.rawTcpopt-in unit (2): theexperimentalflag is off by default and enabled only whenrawTcpis set.Real-environment E2E (manual): verified against a real Cloudflare Tunnel with a private-network MySQL database.
env.VPC_NETWORK.connect(host:3306)under local dev returned a genuine MySQL server greeting and executed a Drizzle query end-to-end, matching deployed behaviour. (No tunnel IDs, database hosts, or account identifiers are included here.)Build, typecheck,
oxfmt, andoxlintare green.PR template checklist (to fill in the actual PR)
Fixes #14710.
remote-bindings-connect.spec.ts, plus manual real-tunnel E2E as described above.connect()over VPC Networks); no new user-facing API or flag is introduced.
