Complete Set up guide

Cloning the Repository

• First you need to clone the Repo by running the below command

git clone https://github.com/JabadeSusheelKrishna/FHIR_prototype_implementation.git

• If you are unable to clone the Above repository, You can Just download Zip File
• Now, if you are able to see a folder named FHIR_prototype_Implementation then congrats. you are able to Download Our server in you Local Machine.

Setting Up Servers

• Now Lets first Setup the Central Server and Patient Consent Server by running below code.
• if you are not in FHIR_prototype_Implementation directory, the go to that directory by :

cd FHIR_prototype_Implementation

• Now go to Server_Comm_test folder by running the following :

cd Server_Comm_test

• Now try to run the main_servers.sh by following command :

./main_servers.sh

If you are unable to run above command, then try below

• run the following command to start the central server :

python3 central_server.py

• Now Lets Run the Patient Consent Server by running the following command :

python3 patient_consent.py

• If you are able to see Server getting run on both codes, then you are successfully able to run Central Server
• (Note : Central server doesn't gets executed because of some module error, please install them/ upgrade them)
• Please donot reload any of the servers. Because data for now is stored in Volatile memory.

Now lets setup the Hospital Servers

• Run Hospital server by running the following commands. Also make sure that you are in Server_Comm_test directory

python3 hos_a_server.py

• if you are trying to test on the Single system, then for multiple hospitals test, please run the hos_b_server.py and hos_c_server.py. because the IP address is same, so common port can create and issue.
• in case of multiple systems, You can run hos_a_server.py in different systems. because the Ip address changes for each system. So common port is not an issue.
• Now we also have to run the FHIR server to store patient data. for that run the below command :

./fhir_server.sh <port_number>

IF you are not able to run above command, then try running below commands

• Come Out of the Server_Comm_test folder by running :

cd ..

• Now go to hapi-fhir-jpaserver-starter folder by running the following command :

cd hapi-fhir-jpaserver-starter

• run the Docker on 8000 port by running the following command :

sudo docker run -p 8000:8080 hapiproject/hapi:latest

• Enter your system password if asked.
• if you are able to see 0 deleted text getting repeated, then your FHIR implementation is working
• if you want to run for multiple hospitals, change the port to 8001, 8002 ... respectively and remember that hos_b_server.py and hos_c_server.py are linked to it respectively.

Registering Orgainzation

• go to browser and search the following :

localhost:<port_of_fhir>

• Now if you are able to see website, then your Docker server is running correctly.
• Now in left menu, search for the Organization.
• Go to Crud operations
• Go to search text field.
• Type the following in text field :

{"resourceType" : "Organization"}

• click Search.
• You should be able to see success message. (200/201 response code)

Running the UI :

• Open VS code and Open Server_Comm_test folder in it.
• Now go to Webspace/Hos_1 folder and there you can see home_portal.html file.
• Make sure you have live server extension.
• Now right click the home_portal.html file. and click open with liveserver
• You will now get redirected to the webpage. (Note : if you are getting any errors, please check script.js in Same directory. Make sure that all the links provided are correct)

Few Important Points to Remember :

• If you want to work in single system, them make use of Ports. (i.e make sure that servers are ran on different Ports).
  • also make sure that in text field of ip address, you need to provide http://127.0.0.1:<port>
• If you are working on different systems, then make sure that both systems are on network. then type ifconfg or ip address to get the ip address of that system.
  • suppose the ip address of the system where hospital server - 1 is running is 10.20.30.40 then during registration, please enter http://10.20.30.40:<port_where_server_is_running>.
  • If you want to have more hospitals, then just copy the hos_a_server.py and change the Port number and FHIR server port in code (you can find them in Line 4 and 5
  • Similarly, for webiste, just change the script.js accordingly.

Youtube Demo Video :

Below Video Guides you in setting up the project in your PC.

Application Part :

• For application, clone the swaroop_final branch.
• There you can find a folder named patient_consent. You can find react native app there.
• Just cd to that directory and install packages and run the App.

cd patient_consent
npm install
npm start

• make sure that you update

Test cases that we tried on this system.

• (tested) One of the Hospital Has data and the other doesn't has the data
• (tested) More than one Hospital has the data and has consent to share
• (tested) All the hospitals have data of a patient and consent to share
• (tested) Hospital asking data without consent
• (tested) Hospitals having data but doesn't have share consent
• (tested) User neglects the consent
• (tested) Hospital with wrong access token (during get-data) or passowrd (during Login)
• (tested) No hospital has data of the patient
• (tested) reload of Central server without issues
• (tested) Adding patient details into the FHIR server
• (tested) Adding Patient hash id and name in Hospital Local Server
• (not tested) Deleting the patient from FHIR server but not from Hospital local server
• (not tested) Trying to send request to Hospital without front end, and without patient consent.
• (not tested) Hospital servers accessing same FHIR server.
• (not tested) Verifying Hospital credentials during the Patient consent.

Thank you for providing the oppurtunity
